0305-2 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN PIN RCPT .025-.037 SOLDER

Part	Operating Temperature [Min]	Operating Temperature [Max]	Socket Depth	Socket Depth	Mounting Hole Diameter [diameter]	Mounting Hole Diameter	Accepts Pin Diameter [Min]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Max]	Accepts Pin Diameter [Min]	Termination	Tail Type	Contact Finish	Flange Diameter [diameter]	Flange Diameter [diameter]	Contact Finish Thickness	Contact Finish Thickness	Contact Material	Length - Overall [x]	Length - Overall [x]	Pin Hole Diameter [diameter]	Pin Hole Diameter [diameter]	Accepts Square Pin Size	Accepts Square Pin Size
Mill-Max Manufacturing Corp. 0305-2-15-15-47-27-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Gold	0.076 in	1.93 mm	30 Áin	0.76 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 0305-2-15-01-47-01-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Tin-Lead	0.076 in	1.93 mm	200 Áin	5.08 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 0305-2-15-80-47-14-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Gold	0.076 in	1.93 mm	10 Áin	0.25 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 0305-2-15-80-47-27-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Gold	0.076 in	1.93 mm	30 Áin	0.76 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 0305-2-15-80-47-80-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Tin	0.076 in	1.93 mm	200 Áin	5.08 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 0305-2-15-15-47-14-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Gold	0.076 in	1.93 mm	10 Áin	0.25 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
Mill-Max Manufacturing Corp. 0305-2-15-01-47-27-10-0	-55 C	125 °C	3.94 mm	0.155 in	0.061 "	1.55 mm	0.64 mm	0.037 in	0.94 mm	0.025 in	Solder	No Tail	Gold	0.076 in	1.93 mm	30 Áin	0.76 Ám	Beryllium Copper	3.94 mm	0.155 in	0.051 in	1.3 mm	0.025 in	0.64 mm
