857-058 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 58POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Card Type | Features | Contact Material | Color | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Number of Rows [custom] | Flange Feature | Pitch | Pitch | Number of Positions/Bay/Row | Mounting Type | Gender | Contact Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Card Extender | Copper Alloy | Black | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 29 | Board Edge Straddle Mount | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | ||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Wire Wrap | Tin | 2 | 3.96 mm | 0.156 in | 29 | Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Solder | Tin | 2 | Side Mount Opening Unthreaded | 3.96 mm | 0.156 in | 29 | Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | 0.128 " | 3.25 mm | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Card Extender | Copper Alloy | Black | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | 29 | Board Edge Straddle Mount | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Solder | 0.25 Ám | 10 Áin | Gold | 2 | 3.96 mm | 0.156 in | 29 | Right Angle Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 125 °C | -40 C | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Wire Wrap | Tin | 2 | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | 29 | Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Solder | Tin | 2 | 3.96 mm | 0.156 in | 29 | Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | ||||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Solder | 0.25 Ám | 10 Áin | Gold | 2 | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | 29 | Right Angle Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 125 °C | -40 C | 0.156 " | 3.96 mm | |
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Solder Eyelet(s) | Tin | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 29 | Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Non Specified - Dual Edge | Copper Alloy | Black | Solder | Tin | 2 | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | 29 | Through Hole | Female | Semi Bellows | 58 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 125 °C | -40 C |
