RCLAMP3552 Series
Manufacturer: Semtech Corporation
Beta
⌘K
2-LINE, 3.5V, 0.4PF, ESD, SLP1006N3T ROHS COMPLIANT: YES
| Part | Package / Case | Operating Temperature [Min] | Operating Temperature [Max] | Bidirectional Channels | Mounting Type | Voltage - Clamping (Max) @ Ipp [Max] | Power Line Protection | Type | Supplier Device Package | Current - Peak Pulse (10/1000µs) | Voltage - Breakdown (Min) [Min] | Applications | Capacitance @ Frequency | Voltage - Reverse Standoff (Typ) | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Semtech Corporation | 0402 (1006 Metric) 3-XDFN | -40 C | 125 °C | 2 | Surface Mount | 6.5 V | Zener | SLP1006N3T | 4 A | 7.5 V | General Purpose | 0.3 pF | 3.5 V | |||
 Semtech Corporation | 0402 (1006 Metric) | -40 C | 125 °C | 2 | Surface Mount | 6.5 V | Zener | SLP1006N3T | 4 A | 7.5 V | USB | 0.4 pF | 3.5 V | Automotive | AEC-Q100 |
