833-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 25POS 0.156
| Part | Material - Insulation | Termination Rows | Card Type | Read Out | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Number of Rows | Color | Termination | Gender | Contact Type | Contact Material | Number of Positions | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Number of Positions/Bay/Row | Card Thickness [Max] | Card Thickness [Min] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Through Hole | 125 °C | -40 C | 1 | Green | Solder | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Through Hole | 125 °C | -40 C | 1 | Green | Wire Wrap | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Through Hole | 125 °C | -40 C | 1 | Green | Solder Eyelet(s) | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount M3 Threaded Insert Top Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Right Angle Through Hole | 125 °C | -40 C | 1 | Green | Solder | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Through Hole | 125 °C | -40 C | 1 | Green | Wire Wrap | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.156 " | 3.96 mm | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Through Hole | 125 °C | -40 C | 1 | Green | Solder | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Right Angle Through Hole | 125 °C | -40 C | 1 | Green | Solder | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Right Angle Through Hole | 125 °C | -40 C | 1 | Green | Solder | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Through Hole | 125 °C | -40 C | 1 | Green | Wire Wrap | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Non Specified - Single Edge | Single | Right Angle Through Hole | 125 °C | -40 C | 1 | Green | Solder | Female | Cantilever | Copper Alloy | 25 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Gold | 25 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | M3 Threaded Insert Top Mount Opening |
