PTC20 Series

Manufacturer: Sullins Connector Solutions

Catalog

CONN HEADER R/A 40POS 2.54MM

Part	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Rows [custom]	Insulation Color	Contact Length - Mating	Contact Length - Mating	Contact Material	Contact Shape	Connector Type	Insulation Material	Insulation Height [z]	Insulation Height [z]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Shrouding	Pitch - Mating	Pitch - Mating	Number of Positions	Material Flammability Rating	Contact Length - Post	Contact Length - Post	Contact Finish - Post	Mounting Type	Contact Type	Current Rating (Amps)	Style	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Number of Positions Loaded	Termination	Fastening Type	Overall Contact Length	Overall Contact Length	Insulation Height	Insulation Height	Overall Contact Length [x]	Overall Contact Length [x]	Number of Rows
Sullins Connector Solutions PTC20DBBN	100 çin	2.54 çm	2	Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic	6.1 mm	0.24 in	2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	40	UL94 V-0	5.84 mm	0.23 "	Tin	Right Angle Through Hole	Male Pin	3 A	Board to Board Cable	0.1 in	2.54 mm	All	Solder	Push-Pull
Sullins Connector Solutions PTC20DAGN	100 çin	2.54 çm	2	Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	40	UL94 V-0	18.29 mm	0.72 "	Tin	Through Hole	Male Pin	3 A	Board to Board Cable	0.1 in	2.54 mm	All	Solder	Push-Pull	26.67 mm	1.05 in	0.1 in	2.54 mm
Sullins Connector Solutions PTC20DADN	100 çin	2.54 çm	2	Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	40	UL94 V-0	10.67 mm	0.42 in	Tin	Through Hole	Male Pin	3 A	Board to Board Cable	0.1 in	2.54 mm	All	Solder	Push-Pull			0.1 in	2.54 mm	19.05 mm	0.75 in
Sullins Connector Solutions PTC20SAGN	100 çin	2.54 çm		Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	20	UL94 V-0	18.29 mm	0.72 "	Tin	Through Hole	Male Pin	3 A	Board to Board Cable			All	Solder	Push-Pull	26.67 mm	1.05 in	0.1 in	2.54 mm			1
Sullins Connector Solutions PTC20SAEN	100 çin	2.54 çm		Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	20	UL94 V-0	13.21 mm	0.52 in	Tin	Through Hole	Male Pin	3 A	Board to Board Cable			All	Solder	Push-Pull	21.59 mm	0.85 in	0.1 in	2.54 mm			1
Sullins Connector Solutions PTC20SABN	100 çin	2.54 çm		Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	20	UL94 V-0	5.84 mm	0.23 "	Tin	Through Hole	Male Pin	3 A	Board to Board Cable			All	Solder	Push-Pull	14.22 mm	0.56 in	0.1 in	2.54 mm			1
Sullins Connector Solutions PTC20SBAN	100 çin	2.54 çm		Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	20	UL94 V-0	3.05 mm	0.12 in	Tin	Right Angle Through Hole	Male Pin	3 A	Board to Board Cable			All	Solder	Push-Pull			0.14 in	3.56 mm			1
Sullins Connector Solutions PTC20DAAN	100 çin	2.54 çm	2	Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	40	UL94 V-0	3.05 mm	0.12 in	Tin	Through Hole	Male Pin	3 A	Board to Board Cable	0.1 in	2.54 mm	All	Solder	Push-Pull			0.1 in	2.54 mm	11.43 mm	0.45 in
Sullins Connector Solutions PTC20DAEN	100 çin	2.54 çm	2	Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	40	UL94 V-0	13.21 mm	0.52 in	Tin	Through Hole	Male Pin	3 A	Board to Board Cable	0.1 in	2.54 mm	All	Solder	Push-Pull	21.59 mm	0.85 in	0.1 in	2.54 mm
Sullins Connector Solutions PTC20DABN	100 çin	2.54 çm	2	Black	0.23 in	5.84 mm	Copper Alloy	Square	Header	Polyester Thermoplastic			2.54 µm	100 µin	Unshrouded	0.1 "	2.54 mm	40	UL94 V-0	5.84 mm	0.23 "	Tin	Through Hole	Male Pin	3 A	Board to Board Cable	0.1 in	2.54 mm	All	Solder	Push-Pull	14.22 mm	0.56 in	0.1 in	2.54 mm
