846-027 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 27POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Contact Type | Number of Positions/Bay/Row | Flange Feature | Contact Material | Read Out | Number of Rows | Number of Positions | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Gender | Color | Card Thickness [Max] | Card Thickness [Min] | Pitch | Pitch | Mounting Type | Termination | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Through Hole | Solder | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Through Hole | Solder | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Flush Mount Top Opening Unthreaded | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Right Angle Through Hole | Solder | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Through Hole | Solder | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Right Angle Through Hole | Solder | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Flush Mount Top Opening Unthreaded | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Through Hole | Solder | 3.96 mm | 0.156 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Right Angle Through Hole | Solder | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Flush Mount Top Opening Unthreaded | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Through Hole | Solder | 3.25 mm | 0.128 " |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Right Angle Through Hole | Solder | 3.25 mm | 0.128 " | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 0.25 Ám | 10 Áin | Cantilever | 27 | M3 Threaded Insert Top Mount Opening | Copper Alloy | Single | 1 | 27 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Female | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 3.18 mm | 0.125 in | Right Angle Through Hole | Solder |
