858-L03 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN PLUG FMALE 3P GOLD SLDR CUP
| Part | Contact Finish - Mating | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Primary Material | Applications | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating | Insert Material | Voltage Rating | Color | Backshell Material, Plating | Mounting Type | Ingress Protection | Fastening Type | Shell Finish | Current Rating (Amps) | Shell Size - Insert | Shell Material | Orientation | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Gold | Brass | 85 °C | -40 C | Metal | Industrial Medical | Backshell Coupling Nut Strain Relief | 0.25 µm | 10 µin | UL94 V-0 | Polybutylene Terephthalate (PBT) | 250 V | Silver | Aluminum Alloy Nickel | Free Hanging (In-Line) | IP67 - Dust Tight Waterproof | Threaded | Nickel | 4 A | M12-3 | Aluminum Alloy | A | Plug Female Sockets |
