1761608 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN HEADER VERT 24POS 2.54MM

Part	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post	Contact Length - Post	Shrouding	Insulation Color	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Pitch - Mating	Pitch - Mating	Voltage Rating	Contact Finish - Mating	Connector Type	Material Flammability Rating	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Fastening Type	Contact Length - Mating	Contact Length - Mating	Mounting Type	Number of Rows	Contact Finish - Post	Features	Insulation Height [z]	Insulation Height [z]	Current Rating (Amps)	Style	Termination	Insulation Material	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Number of Positions Loaded	Number of Positions	Contact Shape	Contact Type
TE Connectivity Raychem Cable Protection 2-1761608-8	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Blue	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	24	Square	Male Pin
TE Connectivity Raychem Cable Protection 1-1761608-5	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	50	Square	Male Pin
TE Connectivity Raychem Cable Protection 1761608-3	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	10	Square	Male Pin
TE Connectivity Raychem Cable Protection 2-1761608-7	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Blue	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	20	Square	Male Pin
TE Connectivity Raychem Cable Protection 3-1761608-1	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Blue	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	34	Square	Male Pin
TE Connectivity Raychem Cable Protection 1761608-9	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	26	Square	Male Pin
TE Connectivity Raychem Cable Protection 1-1761608-1	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	34	Square	Male Pin
TE Connectivity Raychem Cable Protection 3-1761608-5	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Blue	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	50	Square	Male Pin
TE Connectivity Raychem Cable Protection 2-1761608-1	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Blue	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	6	Square	Male Pin
TE Connectivity Raychem Cable Protection 1-1761608-6	30 Áin	0.76 Ám	0.102 in	2.6 mm	Shrouded - 4 Wall	Black	2.54 mm	0.1 in	0.1 in	2.54 mm	250 VAC	Gold or Gold-Palladium	Header	UL94 V-0	-65 ░C	105 ░C	Phosphor Bronze	Latch Lock/Eject Hooks Short	6.02 mm	0.237 in	Through Hole	2	Tin	Keying Slot	0.404 in	10.26 mm	1 A	Board to Cable/Wire	Solder	Polybutylene Terephthalate (PBT)	2.54 µm	100 µin	All	60	Square	Male Pin
