282833 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
TERM BLOCK HDR 6POS VERT 10MM
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Header Orientation | Material Flammability Rating | Color | Number of Positions | Pitch [x] | Pitch [x] | Mounting Type | Insulation Height | Insulation Height | Positions Per Level | Termination Style | Contact Material | Number of Levels | Contact Mating Finish | Type | Contact Tail Length | Contact Tail Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | UL94 V-0 | Green | 6 | 0.394 in | 10 mm | Through Hole | 0.079 in | 2 mm | 6 | Solder | Brass | 1 | Tin | Header Male Pins Unshrouded | 3.5 mm | 0.138 in |
TE Connectivity Raychem Cable Protection | -40 °C | 110 °C | Vertical | UL94 V-0 | Green | 4 | 0.394 in | 10 mm | Through Hole | 0.079 in | 2 mm | 4 | Solder | Brass | 1 | Tin | Header Male Pins Unshrouded | 3.5 mm | 0.138 in |
