Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
Circular Push Pull Connectors FIXED RECEPTACLE NUT FIXING
| Part | Shell Size - Insert | Mounting Type | Number of Positions | Insert Material | Cable Opening [Min] [diameter] | Cable Opening [Min] [diameter] | Cable Opening [Max] [diameter] | Cable Opening [Max] [diameter] | Color | Contact Finish - Mating | Current Rating (Amps) | Orientation | Connector Type | Contact Material | Features | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Primary Material | Shell Material | Ingress Protection | Operating Temperature [Min] | Operating Temperature [Max] | Fastening Type | Backshell Material, Plating | Shell Finish | Cable Opening [diameter] | Cable Opening [diameter] | Cable Opening [diameter] | Cable Opening [custom] | Cable Opening [custom] | Cable Opening [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
310 | Free Hanging (In-Line) | 10 | Polyetheretherketone (PEEK) | 0.185 in | 4.7 mm | 0.201 in | 5.1 mm | Silver | Gold | 7 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | |||||||
306 | Free Hanging (In-Line) | 6 | Polyetheretherketone (PEEK) | Silver | Gold | 12 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | |||||||||||
310 | Free Hanging (In-Line) | 10 | Polyetheretherketone (PEEK) | Silver | Gold | 7 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | 0.264 in 0.28 in | 6.7 mm | 7.1 mm | ||||||||
308 | Free Hanging (In-Line) | 8 | Polyetheretherketone (PEEK) | Silver | Gold | 7 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | 5.7 mm | 0.224 in 0.24 in | 6.1 mm | ||||||||
314 | Free Hanging (In-Line) | 14 | Polyetheretherketone (PEEK) | Silver | Gold | 5 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | 5.2 mm 5.6 mm | 0.205 in 0.22 in | |||||||||
302 | Free Hanging (In-Line) | 2 | Polyetheretherketone (PEEK) | 0.295 in | 7.5 mm | 0.311 in | 7.9 mm | Silver | Gold | 20 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | |||||||
306 | Free Hanging (In-Line) | 6 | Polyetheretherketone (PEEK) | 0.295 in | 7.5 mm | 0.311 in | 7.9 mm | Silver | Gold | 12 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | |||||||
310 | Free Hanging (In-Line) | 10 | Polyetheretherketone (PEEK) | Silver | Gold | 7 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | 5.7 mm | 0.224 in 0.24 in | 6.1 mm | ||||||||
310 | Free Hanging (In-Line) | 10 | Polyetheretherketone (PEEK) | 0.185 in | 4.7 mm | 0.201 in | 5.1 mm | Silver | Gold | 7 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | |||||||
306 | Free Hanging (In-Line) | 6 | Polyetheretherketone (PEEK) | Silver | Gold | 12 A | Keyed | Female Sockets Male Pins Receptacle | Bronze | Backshell | 59 Áin | 1.5 Ám | Metal | Brass | IP50 | -55 °C | 250 °C | Push-Pull | Brass Chrome | Chrome | 5.7 mm | 0.224 in 0.24 in | 6.1 mm |
