ECA-1CH Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP ALUM 3300UF 20% 16V RADIAL

Part	Capacitance	Package / Case	Ripple Current @ High Frequency	Polarization	Lifetime @ Temp.	Voltage - Rated	Tolerance	Mounting Type	Ripple Current @ Low Frequency	Applications	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Operating Temperature [Min]	Operating Temperature [Max]	Ratings	Size / Dimension [diameter]	Size / Dimension [diameter]	Height - Seated (Max) [Max] [z]	Height - Seated (Max)	Height - Seated (Max) [Max]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]
Panasonic Electronic Components ECA-1CHG332B	3.3 mF	Can Radial	1.346 A	Polar	2000 Hrs	16 V	20 %	Through Hole	1.17 A	Automotive	1.063 in	27 mm	0.197 "	5 mm	-55 C	105 ░C	AEC-Q200	0.492 in	12.5 mm
Panasonic Electronic Components ECA-1CHG682	6800 µF	Can Radial	2.047 A	Polar	2000 Hrs	16 V	20 %	Through Hole	1.78 A	General Purpose			0.295 in	7.5 mm	-55 C	105 ░C		0.63 in	16 mm	1.319 in	33.5 mm
Panasonic Electronic Components ECA-1CHG471B	470 µF	Can Radial	418.5 mA	Polar	1000 Hrs	16 V	20 %	Through Hole	310 mA	Automotive		0.492 in	0.197 "	5 mm	-55 C	105 ░C	AEC-Q200	0.315 in	8 mm			12.5 mm
Panasonic Electronic Components ECA-1CHG331B	330 µF	Can Radial	390 mA	Polar	1000 Hrs	16 V	20 %	Through Hole	260 mA	General Purpose		0.492 in	0.197 "	5 mm	-55 C	105 ░C		0.315 in	8 mm			12.5 mm
Panasonic Electronic Components ECA-1CHG101	100 µF	Can Radial	165 mA	Polar	1000 Hrs	16 V	20 %	Through Hole	110 mA	General Purpose	0.472 in		0.079 in	2 mm	-55 C	105 ░C		0.197 in	5 mm		12 mm
Panasonic Electronic Components ECA-1CHG100	10 µF	Can Radial		Polar		16 V	20 %	Through Hole		Automotive					-55 C	105 ░C	AEC-Q200
Panasonic Electronic Components ECA-1CHG332	3.3 mF	Can Radial	1.346 A	Polar	2000 Hrs	16 V	20 %	Through Hole	1.17 A	General Purpose	1.063 in	27 mm	0.197 "	5 mm	-55 C	105 ░C		0.492 in	12.5 mm
Panasonic Electronic Components ECA-1CHG682
Panasonic Electronic Components ECA-1CHG470I	47 µF	Can Radial	115.5 mA	Polar	1000 Hrs	16 V	20 %	Through Hole	77 mA	General Purpose	0.472 in		0.098 in	2.5 mm	-55 C	105 ░C		0.197 in	5 mm		12 mm
Panasonic Electronic Components ECA-1CHG222B	2200 µF	Can Radial	1.058 A	Polar	2000 Hrs	16 V	20 %	Through Hole	920 mA	General Purpose			0.197 "	5 mm	-55 C	105 ░C		0.492 in	12.5 mm				0.866 in	22 mm
