043640 Series
Manufacturer: Molex
Beta
⌘K
CONN HOUSING M 5 POS 3MM CRIMP ST CABLE MOUNT BLACK MICRO-FIT 3.0™ BAG
| Part | Fastening Type | Color | Mounting Type | Pitch [x] | Pitch [x] | Number of Rows | Insulation Material | Contact Termination | Note | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Contact Type | Number of Positions | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | Locking Ramp | Black | Free Hanging (In-Line) | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | Contacts Not Included | -40 °C | 105 ░C | Plug | Male Pin | ||
 Molex | Locking Ramp | Black | Free Hanging (In-Line) | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | Contacts Not Included | -40 °C | 105 ░C | Plug | Male Pin | 11 | |
Molex | Locking Ramp | Black | Panel Mount Snap-In | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | -40 °C | 125 °C | Plug | Male Pin | 9 | ||
Molex | |||||||||||||||
Molex | Locking Ramp | Black | Panel Mount Snap-In | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | -40 °C | 125 °C | Plug | Male Pin | 8 | ||
 Molex | Locking Ramp | Black | Free Hanging (In-Line) | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | Contacts Not Included | -40 °C | 105 ░C | Plug | Male Pin | ||
 Molex | Locking Ramp | Black | Free Hanging (In-Line) | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | Contacts Not Included | -40 °C | 105 ░C | Plug | Male Pin | 7 | |
 Molex | Locking Ramp | Black | Panel Mount Snap-In | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | Contacts Not Included | -40 °C | 105 ░C | Plug | Male Pin | 11 | |
Molex | |||||||||||||||
Molex | Locking Ramp | Black | Panel Mount Snap-In | 3 mm | 0.118 in | 1 | Nylon Polyamide (PA) | Crimp | -40 °C | 125 °C | Plug | Male Pin | 6 | Glow Wire Compliant |
