BK010 Series

Manufacturer: GCT

Catalog

CONN HEADER SMD 5POS 5.08MM

Part	Contact Length - Mating	Contact Length - Mating	Contact Type	Insulation Height	Insulation Height	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Features	Current Rating (Amps)	Connector Type	Pitch - Mating	Pitch - Mating	Fastening Type	Insulation Material	Number of Positions	Contact Finish - Post	Shrouding	Mounting Type	Termination	Contact Shape	Contact Material	Material Flammability Rating	Number of Rows	Insulation Color
GCT BK010-05-C-0850-0864-0508-G	0.335 in	8.51 mm	Male Pin	0.098 "	2.5 mm	All	-40 C	105 ░C	Pick and Place	7.9 A	Header	0.2 "	5.08 mm	Push-Pull	Liquid Crystal Polymer (LCP)	5	Tin	Unshrouded	Surface Mount	Solder	Square	Brass	UL94 V-0	1	Black
GCT BK010-10-C-0850-0864-0508-G	0.335 in	8.51 mm	Male Pin	0.098 "	2.5 mm	All	-40 C	105 ░C	Pick and Place	7.9 A	Header	0.2 "	5.08 mm	Push-Pull	Liquid Crystal Polymer (LCP)	10	Tin	Unshrouded	Surface Mount	Solder	Square	Brass	UL94 V-0	1	Black
GCT BK010-03-C-0850-0864-0508-G	0.335 in	8.51 mm	Male Pin	0.098 "	2.5 mm	All	-40 C	105 ░C	Pick and Place	7.9 A	Header	0.2 "	5.08 mm	Push-Pull	Liquid Crystal Polymer (LCP)		Tin	Unshrouded	Surface Mount	Solder	Square	Brass	UL94 V-0	1	Black
GCT BK010-02-C-0850-0864-0508-G	0.335 in	8.51 mm	Male Pin	0.098 "	2.5 mm	All	-40 C	105 ░C	Pick and Place	7.9 A	Header	0.2 "	5.08 mm	Push-Pull	Liquid Crystal Polymer (LCP)	2	Tin	Unshrouded	Surface Mount	Solder	Square	Brass	UL94 V-0	1	Black
