M50-314 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN, RCPT, 4POS, 1ROW, 1.27MM ROHS COMPLIANT: YES
| Part | Contact Shape | Contact Material | Applications | Insulation Material | Connector Type | Number of Rows | Voltage Rating | Material Flammability Rating | Termination | Fastening Type | Number of Positions | Features | Mounting Type | Pitch - Mating | Pitch - Mating | Insulation Color | Contact Finish - Mating | Insulation Height | Insulation Height | Number of Positions Loaded | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish - Post | Contact Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 4 | Pick and Place | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám |
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 20 | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám | |
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 6 | Pick and Place | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám |
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 2 | Pick and Place | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám |
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 10 | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám | |
Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 20 | Pick and Place | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám |
Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 2 | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám | |
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | 8 | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám | |
 Harwin Inc. | Square | Phosphor Bronze | General Purpose Medical Telecommunications | Nylon 6T Polyamide (PA6T) | Receptacle | 1 | 500 VAC | UL94 V-0 | Solder | Push-Pull | Pick and Place | Surface Mount | 1.27 mm | 0.05 in | Black | Gold | 0.134 in | 3.4 mm | All | -40 C | 105 ░C | Tin | Female Socket | 12 Áin | 0.3 Ám |
