EE1G Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
BLOWER
| Part | Material - Blade | Material - Frame | Bearing Type | Air Flow | Air Flow | Features | Fan Type | Power (Watts) | Operating Temperature | Operating Temperature | Size / Dimension | Size / Dimension [z] | Size / Dimension [x] | Noise | Width [x] | Voltage - Rated | Termination | Size / Dimension [y] | Width [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Steel | Steel | Ball | 14 mł/min | 500 CFM | Capacitor | Blower Centrifugal | 180 W | 60 °C | 60 °C | Rectangular/Rounded | 357 mm | 287 mm | 64 dB(A) | 177 mm | 230 VAC | 3 Wire Leads | ||
 ebm-papst Inc. | Steel | Steel | Ball | 7.56 mł/min | 270 CFM | Capacitor | Blower Centrifugal | 195 W | 50 °C | 50 °C | Rectangular/Rounded | 220 mm | 64 dB(A) | 115 VAC | 3 Wire Leads | 256.5 mm | 130 mm | ||
 ebm-papst Inc. | Steel | Steel | Ball | 12.6 m³/min | 450 CFM | Capacitor | Blower Centrifugal | 180 W | 50 °C | 50 °C | Rectangular/Rounded | 302 mm | 260 mm | 64 dB(A) | 115 VAC | 3 Wire Leads | 170 mm | ||
 ebm-papst Inc. | Steel | Steel | Ball | 8.12 m³/min | 290 CFM | Capacitor | Blower Centrifugal | 200 Watts | 50 °C | 50 °C | Rectangular/Rounded | 220 mm | 68 dB | 230 VAC | 3 Wire Leads | 256.5 mm | 130 mm | ||
ebm-papst Inc. | Steel | Steel | Ball | 7.56 mł/min | 270 CFM | Capacitor | Blower Centrifugal | 195 W | 50 °C | 50 °C | Rectangular/Rounded | 220 mm | 64 dB(A) | 115 VAC | 3 Wire Leads | 256.5 mm | 130 mm | ||
ebm-papst Inc. | Steel | Steel | Ball | 12.6 m³/min | 450 CFM | Capacitor | Blower Centrifugal | 180 W | 60 °C | 60 °C | Rectangular/Rounded | 302 mm | 260 mm | 64 dB(A) | 230 VAC | 3 Wire Leads | 170 mm |
