896-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 50POS 0.125
| Part | Termination Rows | Material - Insulation | Color | Operating Temperature [Max] | Operating Temperature [Min] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Material | Termination | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Number of Rows | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions | Contact Finish | Number of Positions/Bay/Row | Read Out | Contact Type | Pitch | Pitch | Gender | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Copper Alloy | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Gold | 50 | Single | Cantilever | 3.18 mm | 0.125 in | Female | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Solder Eyelet(s) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Gold | 25 | Dual | Cantilever | 3.18 mm | 0.125 in | Female | 2 | 2 | Card Extender | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | 0.128 " | 3.25 mm | Copper Alloy | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Gold | 50 | Single | Cantilever | 3.18 mm | 0.125 in | Female | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Gold | 50 | Single | Cantilever | 3.18 mm | 0.125 in | Female | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Gold | 25 | Dual | Cantilever | 3.18 mm | 0.125 in | Female | 2 | 2 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Gold | 50 | Single | Cantilever | 3.18 mm | 0.125 in | Female | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Gold | 25 | Dual | Cantilever | 3.18 mm | 0.125 in | Female | 2 | 2 | |||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | 4-40 Threaded Insert Top Mount Opening | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 1 | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Gold | 50 | Single | Cantilever | 3.18 mm | 0.125 in | Female | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | Copper Alloy | Solder | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Gold | 25 | Dual | Cantilever | 3.18 mm | 0.125 in | Female | 2 | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Black | 125 °C | -40 C | M3 Threaded Insert Top Mount Opening | Copper Alloy | Wire Wrap | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 50 | Gold | 25 | Dual | Cantilever | 3.18 mm | 0.125 in | Female | 2 | 2 |
