CXM-11 Series

Catalog

LED COB CXM-11 GEN3 WHT SQ 5000K

Part	Configuration	Color	Temperature - Test	Size / Dimension [y]	Size / Dimension [x]	Voltage - Forward (Vf) (Typ)	Lens Type	Type	Viewing Angle	CCT (K)	CCT (K)	CRI (Color Rendering Index)	Height [z]	Current - Max [Max]	Light Emitting Surface (LES) [diameter]	Luminous Flux @ Current/Temperature	Current - Test	Lumens/Watt @ Current - Test
Luminus Devices Inc. CXM-11-50-90-36-AB00-F2-3	Square	Cool White	85 °C	18.49 mm	18.49 mm	33.8 V	Flat	Chip On Board (COB)	120 °	5000 K	3-Step MacAdam Ellipse	90	1.37 mm	1.08 A	11.71 mm
Luminus Devices Inc. CXM-11-50-70-36-AB00-F2-5	Square	Cool White	85 °C	18.49 mm	18.49 mm	33.8 V	Flat	Chip On Board (COB)	120 °	5000 K	3-Step MacAdam Ellipse	70	1.37 mm	1.08 A	11.71 mm
Luminus Devices Inc. CXM-11-50-70-36-AB00-F2-3	Square	Cool White	85 °C	18.49 mm	18.49 mm	33.8 V	Flat	Chip On Board (COB)	120 °	5000 K	3-Step MacAdam Ellipse	70	1.37 mm	1.08 A	11.71 mm
Luminus Devices Inc. CXM-11-50-80-36-AA00-F2-3	Rectangle	Cool White	85 °C	19 mm	19 mm	35 V	Flat	Chip On Board (COB)	120 °	5000 K	3-Step MacAdam Ellipse	80	1.37 mm	640 mA	11 mm	1335 lm	320 mA	119 lm/W
Luminus Devices Inc. CXM-11-65-70-36-AB00-F2-3	Square	Cool White	85 °C	18.49 mm	18.49 mm	33.8 V	Flat	Chip On Board (COB)	120 °	6500 K		70	1.37 mm	1.08 A	11.71 mm
Luminus Devices Inc. CXM-11-65-80-36-AC00-F2-5	Square	Cool White	85 °C	18.49 mm	18.49 mm	33.8 V	Flat	Chip On Board (COB)	120 °	6500 K		80	1.37 mm	1.08 A	11.71 mm
Luminus Devices Inc. CXM-11-50-70-36-AC30-F4-5	Square	Cool White	85 °C	19 mm	19 mm	33.8 V	Flat	Chip On Board (COB)	120 °	5000 K	5-Step MacAdam Ellipse	70	1.37 mm	1 A	11.7 mm	2595 lm	450 mA	171 lm/W
Luminus Devices Inc. CXM-11-65-70-36-AA30-F4-3	Square	Cool White	85 °C			33.8 V	Flat	Chip On Board (COB)	120 °	6500 K		70	1.37 mm	1.05 A	11.7 mm	2595 lm	450 mA	171 lm/W
Luminus Devices Inc. CXM-11-65-80-36-AB00-F2-5	Square	Cool White	85 °C	18.49 mm	18.49 mm	33.8 V	Flat	Chip On Board (COB)	120 °	6500 K		80	1.37 mm	1.08 A	11.71 mm
Luminus Devices Inc. CXM-11-40-80-36-AC00-F2-3	Square	Neutral White	85 °C	19 mm	19 mm	35 V	Flat	Chip On Board (COB)	120 °	4000 K	3-Step MacAdam Ellipse	80	1.37 mm	960 mA	11 mm	2040 lm	480 mA	121 lm/W
