34412 Series

Catalog

HOOK-UP STRND 12AWG GRN

Part	Length	Length	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Conductor Material	Wire Gauge	Operating Temperature [Min]	Operating Temperature [Max]	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Cable Type	Ratings	Jacket (Insulation) Material	Jacket Color	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness
Belden Inc. 34412 005500	152.4 m	500 ft	0.19 in	4.83 mm	Copper Tinned	12 AWG	-30 ░C	105 ░C	30 AWG	65	300 VDC	Hook-Up	UL Style 3191	Chlorosulfonated Polyethylene (CSPE)	Green	1.3 mm	0.051 in
Belden Inc. 34412 0103000	914.4 m	3000 '	0.19 in	4.83 mm	Copper Tinned	12 AWG	-30 ░C	105 ░C	30 AWG	65	300 VDC	Hook-Up	UL Style 3191	Chlorosulfonated Polyethylene (CSPE)	Black	1.3 mm	0.051 in
Belden Inc. 34412 002500	152.4 m	500 ft	0.19 in	4.83 mm	Copper Tinned	12 AWG	-30 ░C	105 ░C	30 AWG	65	300 VDC	Hook-Up	UL Style 3191	Chlorosulfonated Polyethylene (CSPE)	Red	1.3 mm	0.051 in
Belden Inc. 34412 010500	152.4 m	500 ft	0.19 in	4.83 mm	Copper Tinned	12 AWG	-30 ░C	105 ░C	30 AWG	65	300 VDC	Hook-Up	UL Style 3191	Chlorosulfonated Polyethylene (CSPE)	Black	1.3 mm	0.051 in
