GF-324 Series
Manufacturer: CW Industries
Beta
⌘K
SWITCH SLIDE SPDT 3A 125V
| Part | Actuator Material | Mechanical Life | Electrical Life | Switch Travel | Voltage Rating - AC | Contact Finish | Termination Style | Switch Function | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Mounting Type | Circuit | Voltage Rating - DC | Actuator Length [x] | Current Rating (Amps) | Contact Timing | Actuator Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CW Industries | Nylon 6/6 Polyamide (PA66) | 10000 Steps | 6000 Cycles | 4.01 mm | 125 V | Silver | PC Pin | On-On | -10 °C | 104 °C | Copper | Panel Mount | SPDT | 125 VDC | 8.74 mm | 3 A 500 mA | Not Specified | Standard |
 CW Industries | Nylon 6/6 Polyamide (PA66) | 10000 Steps | 6000 Cycles | 4.01 mm | 125 V | Silver | PC Pin | On-On | -10 °C | 104 °C | Copper | Panel Mount | SPDT | 125 VDC | 8.74 mm | 3 A 500 mA | Not Specified | Standard |
 CW Industries | Nylon 6/6 Polyamide (PA66) | 10000 Steps | 6000 Cycles | 4.01 mm | 125 V | Silver | Wire Wrap | On-On | -10 °C | 104 °C | Copper | Panel Mount | SPDT | 125 VDC | 8.74 mm | 3 A 500 mA | Not Specified | Standard |
CW Industries | Nylon 6/6 Polyamide (PA66) | 10000 Steps | 6000 Cycles | 4.01 mm | 125 V | Silver | PC Pin | On-On | -10 °C | 104 °C | Copper | Through Hole | SPDT | 125 VDC | 8.74 mm | 3 A 500 mA | Not Specified | Standard |
 CW Industries | Nylon 6/6 Polyamide (PA66) | 10000 Steps | 6000 Cycles | 4.01 mm | 125 V | Silver | Solder Lug | On-On | -10 °C | 104 °C | Copper | Panel Mount | SPDT | 125 VDC | 8.74 mm | 3 A 500 mA | Not Specified | Standard |
