CNB.M0 Series
Manufacturer: LEMO
Beta
⌘K
CIRCULAR PUSH PULL CONNECTORS 8P CABLE MT RECPT
| Part | Shielding | Color | Mounting Type | Applications | Termination | Mounting Feature | Number of Positions | Primary Material | Connector Type | Fastening Type | Shell Size - Insert | Shell Material | Contact Finish - Mating | Current Rating (Amps) | Insert Material | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Ingress Protection |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
LEMO | Unshielded | Gray | Panel Mount Through Hole | Automotive Industrial Medical Testing Equipment & Measurement | Solder | Front and Rear Side Nut | 8 | Plastic | Receptacle Female Sockets | Detent Lock Push-Pull | M08 | Polysulfone (PSU) | Gold | 10 A | Polyetheretherketone (PEEK) | 150 °C | -50 °C | B | IP66 - Dust Tight Water Resistant |
LEMO | Unshielded | Gray Red | Panel Mount | Automotive Industrial Medical Testing Equipment & Measurement | Bulkhead - Rear Side Nut | 6 | Plastic | Receptacle Female Sockets | Detent Lock Push-Pull | M06 | Polysulfone (PSU) | Gold | 12 Amps | Polyetheretherketone (PEEK) | 150 °C | -50 °C | B | IP66 - Dust Tight Water Resistant |
