859RD04 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN PLUG FMALE 4P GOLD SLDR CUP
| Part | Primary Material | Number of Positions | Mounting Type | Material Flammability Rating | Shell Material | Contact Material | Shielding | Connector Type | Contact Finish - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Current Rating (Amps) | Fastening Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insert Material | Voltage Rating | Applications | Shell Finish | Shell Size - Insert | Color | Mounting Feature | Ingress Protection | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Metal | 4 | Panel Mount | UL94 V-0 | Brass | Brass | Shielded | Plug Female Sockets | Gold | 85 °C | -40 C | 4 A | Threaded | 0.25 µm | 10 µin | Polybutylene Terephthalate (PBT) | 250 V | Industrial Medical | Nickel | M12-4 | Silver | Bulkhead - Front Side Nut | IP67 - Dust Tight Waterproof | D |
 NorComp Inc. | Metal | 4 | Panel Mount | UL94 V-0 | Brass | Brass | Shielded | Receptacle Male Pins | Gold | 85 °C | -40 C | 4 A | Threaded | 0.25 µm | 10 µin | Polybutylene Terephthalate (PBT) | 250 V | Industrial Medical | Nickel | M12-4 | Silver | Bulkhead - Front Side Nut | IP67 - Dust Tight Waterproof | D |
