842-011 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 11POS 0.100
| Part | Termination Rows | Material - Insulation | Contact Finish | Flange Feature | Read Out | Contact Material | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Mounting Type | Contact Type | Number of Positions | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Color | Number of Positions/Bay/Row | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Gender | Card Type | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder Eyelet(s) | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Flush Mount Top Opening Unthreaded | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Flush Mount M3 Threaded Insert Top Opening | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Wire Wrap | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Floating Bobbin Flush Mount | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | 0.116 " | 2.95 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Flush Mount Side Opening Unthreaded | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | 0.128 " | 3.25 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Flush Mount Top Opening Unthreaded | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Right Angle Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | 0.156 " | 3.96 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Wire Wrap | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | Gold | Flush Mount Top Opening Unthreaded | Single | Copper Alloy | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Through Hole | Cantilever | 11 | Solder | 125 °C | -40 C | Green | 11 | 0.1 " | 2.54 mm | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | 0.156 " | 3.96 mm |
