SSA-EB1 Series
Manufacturer: BANNER ENGINEERING
Beta
⌘K
SSA-EB1 30 MM MOUNT EMERGENCY STOP PUSH BUTTON:
| Part | Panel Cutout Dimensions [diameter] | Reset Operation | Voltage Rating - DC | Circuit | Mounting Type | Ingress Protection | Operating Temperature [Max] | Operating Temperature [Min] | Switch Function | Features | Termination Style | Current Rating (Amps) | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BANNER ENGINEERING | 30 mm | Pull Twist | 30 V | DPST-NC | Panel Mount Front | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | On-Off | Control Box Enclosure | Connector | 2 A | |
 BANNER ENGINEERING | Pull Twist | 24 V | DPST-NC | Chassis Mount | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | On-Off | Control Box Enclosure Illuminated (Red) | Connector | 2 A | 24 V | |
 BANNER ENGINEERING | Pull Twist | 24 V | 3PST-2NC/1NO | Chassis Mount | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | Off-On On-Off | Control Box Enclosure Illuminated (Red) | Connector | 2 A | 24 VAC/DC | |
 BANNER ENGINEERING | Twist | 24 V | DPST-NC | Chassis Mount | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | On-Off | Control Box Enclosure Padlock Style | Connector | 2 A | ||
 BANNER ENGINEERING | 30 mm | Pull Twist | 24 V | 4PST-2NO/2NC | Panel Mount Front | IP65 - Dust Tight Water Resistant | 60 °C | -25 °C | Off-On On-Off | Screw Terminal | 2 A | ||
 BANNER ENGINEERING | Twist | 24 V | 4PST-2NO/2NC | Chassis Mount | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | Off-On On-Off | Control Box Enclosure Padlock Style | Connector | 2 A | ||
 BANNER ENGINEERING | 30 mm | Pull Twist | 24 V | DPST-NC | Panel Mount Front | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | On-Off | Control Box Enclosure | Connector | 2 A | |
BANNER ENGINEERING | 30 mm | Key Lock | 30 V | DPST-NC | Panel Mount Front | IP65 - Dust Tight Water Resistant | 60 °C | -25 °C | On-Off | Screw Terminal | 2 A | ||
BANNER ENGINEERING | 30 mm | Key Lock | 24 V | 4PST-3NC/1NO | Panel Mount Front | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | Off-On On-Off | Illuminated (Red) | Screw Terminal | 2 A | 24 VAC/DC |
BANNER ENGINEERING | 30 mm | Pull Twist | 24 V | 4PST-2NO/2NC | Panel Mount Front | IP65 - Dust Tight Water Resistant | 55 °C | -25 °C | Off-On On-Off | Control Box Enclosure | Connector | 2 A |
