DX0505 Series
Manufacturer: BULGIN LIMITED
Beta
⌘K
LED PANEL MOUNT INDICATOR, VANDAL RESISTANT, RED, 12.2 MM, 12 VDC, 30 MA, 2 CD, IP67 ROHS COMPLIANT: YES
| Part | Lamp Color | Panel Cutout Dimensions | Panel Cutout Dimensions | Ratings | Termination Style | Ingress Protection | Type | Voltage | Panel Cutout Shape | Current | Lens Style | Panel Cutout Dimensions [custom] | Panel Cutout Dimensions [custom] | Millicandela Rating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BULGIN LIMITED | Red | 0.48 in | 12.2 mm | DC | Solder Lug | IP67 | LED | 1.85 V 12 V | Round | 30 mA | Round with Flat Top | 12.1 mm | 0.48 in | 2000 mcd |
 BULGIN LIMITED | Yellow | DC | Solder Lug | IP67 | LED | 24 V | Round | 30 mA | Round with Flat Top | 12.1 mm | 0.48 in | 400 mcd | ||
BULGIN LIMITED | Blue | Solder Lug | IP67 | LED | Round | 25 mA | Round with Flat Top | 12.1 mm | 0.48 in | 1600 mcd | ||||
 BULGIN LIMITED | Red | DC | Solder Lug | IP67 | LED | 24 V | Round | 30 mA | Round with Flat Top | 12.1 mm | 0.48 in | 2000 mcd | ||
 BULGIN LIMITED | Yellow | DC | Solder Lug | IP67 | LED | 12 V | Round | 30 mA | Round with Flat Top | 12.1 mm | 0.48 in | 400 mcd | ||
 BULGIN LIMITED | Red | Solder Lug | IP67 | LED | 1.85 V | Round | 30 mA | Round with Flat Top | 12.1 mm | 0.48 in | 2000 mcd | |||
BULGIN LIMITED | Green | DC | Solder Lug | IP67 | LED | 12 V | Round | 25 mA | Round with Flat Top | 12.1 mm | 0.48 in | 100 mcd | ||
 BULGIN LIMITED | Blue | DC | Solder Lug | IP67 | LED | 12 V | Round | 25 mA | Round with Flat Top | 12.1 mm | 0.48 in | 1600 mcd |
