395-021 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows | Material - Insulation | Mounting Type | Termination | Gender | Contact Finish | Flange Feature | Pitch | Pitch | Number of Rows | Color | Card Type | Contact Type | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row [custom] | Features | Number of Positions | Read Out | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | Solder | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | Card Guides | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Solder | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | Card Guides | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Wire Wrap | Female | Gold | Flush Mount Side Opening Unthreaded | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.128 " | 3.25 mm | |
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Solder | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | Card Guides | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Solder | Female | Gold | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 0.156 " | 3.96 mm | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | Solder | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | Card Guides | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Right Angle Through Hole | Solder | Female | Gold | Flush Mount M3 Threaded Insert Top Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Solder | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | Card Guides | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Wire Wrap | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | Through Hole | Wire Wrap | Female | Gold | 4-40 Threaded Insert Top Mount Opening | 0.1 " | 2.54 mm | 1 | Black | Non Specified - Single Edge | Cantilever | Copper Alloy | -40 C | 105 ░C | 21 | Card Guides | 21 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin |
