451-80 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN HEADER VERT 70POS 2.54MM
| Part | Connector Type | Insulation Material | Contact Shape | Contact Type | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Termination | Number of Rows [custom] | Contact Length - Post [x] | Contact Length - Post [x] | Number of Positions Loaded | Contact Length - Mating | Contact Length - Mating | Shrouding | Voltage Rating | Insulation Color | Material Flammability Rating | Current Rating (Amps) | Number of Positions | Fastening Type | Contact Finish - Post | Contact Material | Mounting Type | Overall Contact Length | Overall Contact Length | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 70 | Push-Pull | Tin | Brass | Through Hole | 33.6 mm | 1.323 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | Push-Pull | Tin | Brass | Through Hole | 21.5 mm | 0.846 in | -55 C | 125 °C | 0.1 " | 2.54 mm | |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 56 | Push-Pull | Tin | Brass | Through Hole | 12.4 mm | 0.488 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 28 | Push-Pull | Tin | Brass | Through Hole | 33.6 mm | 1.323 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 28 | Push-Pull | Tin | Brass | Through Hole | 12.4 mm | 0.488 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 50 | Push-Pull | Tin | Brass | Through Hole | 21.5 mm | 0.846 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 42 | Push-Pull | Tin | Brass | Through Hole | 33.6 mm | 1.323 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 44 | Push-Pull | Tin | Brass | Through Hole | 12.4 mm | 0.488 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 26 | Push-Pull | Tin | Brass | Through Hole | 21.5 mm | 0.846 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
Preci-Dip | Header | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Circular | Male Pin | 0.1 in | 2.54 mm | Solder | 2 | 0.126 " | 3.2 mm | All | 3 mm | 0.118 in | Unshrouded | 150 VDC | Black | UL94 V-0 | 3 A | 16 | Push-Pull | Tin | Brass | Through Hole | 27.4 mm | 1.079 in | -55 C | 125 °C | 0.1 " | 2.54 mm |
