845-066 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 66POS 0.100
| Part | Mounting Type | Number of Positions/Bay/Row | Pitch | Pitch | Termination | Flange Feature | Number of Rows | Gender | Contact Material | Termination Rows | Operating Temperature [Max] | Operating Temperature [Min] | Color | Contact Type | Contact Finish | Read Out | Material - Insulation | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Card Type | Flange Feature [diameter] | Flange Feature [diameter] | Termination Rows [custom] | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Through Hole | 66 | 0.1 " | 2.54 mm | Solder Eyelet(s) | M3 Threaded Insert Top Mount Opening | 1 | Female | Copper Alloy | 1 | 125 °C | -40 C | Green | Cantilever | Gold | Single | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | ||||
 EDAC Inc. | Through Hole | 66 | 0.1 " | 2.54 mm | Solder Eyelet(s) | Floating Bobbin Flush Mount | 1 | Female | Copper Alloy | 1 | 125 °C | -40 C | Green | Cantilever | Gold | Single | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.116 " | 2.95 mm | ||
 EDAC Inc. | Right Angle Through Hole | 66 | 0.1 " | 2.54 mm | Solder | 1 | Female | Copper Alloy | 1 | 125 °C | -40 C | Green | Cantilever | Gold | Single | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.156 " | 3.96 mm | |||
 EDAC Inc. | Through Hole | 33 | 0.1 " | 2.54 mm | Wire Wrap | M3 Threaded Insert Top Mount Opening | Female | Copper Alloy | 125 °C | -40 C | Green | Cantilever | Gold | Dual | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | 2 | ||||
 EDAC Inc. | Right Angle Through Hole | 33 | 0.1 " | 2.54 mm | Solder | Flush Mount Side Opening Unthreaded | Female | Copper Alloy | 125 °C | -40 C | Green | Cantilever | Gold | Dual | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 0.128 " | 3.25 mm | 2 | 2 | ||
 EDAC Inc. | Through Hole | 33 | 0.1 " | 2.54 mm | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | Female | Copper Alloy | 125 °C | -40 C | Green | Cantilever | Gold | Dual | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 2 | 2 | ||||
 EDAC Inc. | Through Hole | 33 | 0.1 " | 2.54 mm | Solder | Floating Bobbin Flush Mount | Female | Copper Alloy | 125 °C | -40 C | Green | Cantilever | Gold | Dual | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 0.116 " | 2.95 mm | 2 | 2 | ||
 EDAC Inc. | Through Hole | 66 | 0.1 " | 2.54 mm | Wire Wrap | 1 | Female | Copper Alloy | 1 | 125 °C | -40 C | Green | Cantilever | Gold | Single | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | |||||
 EDAC Inc. | Through Hole | 33 | 0.1 " | 2.54 mm | Solder | Female | Copper Alloy | 125 °C | -40 C | Green | Cantilever | Gold | Dual | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 0.156 " | 3.96 mm | 2 | 2 | |||
 EDAC Inc. | Through Hole | 66 | 0.1 " | 2.54 mm | Solder | Floating Bobbin Flush Mount | 1 | Female | Copper Alloy | 1 | 125 °C | -40 C | Green | Cantilever | Gold | Single | Diallyl Phthalate (DAP) | 66 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 0.116 " | 2.95 mm |
