CWR-140 Series

Catalog

CONN IDC 40POS 28-30AWG VERT

Part	Number of Positions Loaded	Cable Termination	Board-Side Pitch	Number of Positions	Contact Finish	Color	Contact Finish Thickness	Contact Finish Thickness	Mounting Type	Connector Type	Cable Pitch	Cable Pitch	Row Spacing	Row Spacing	Features	Wire Gauge	Wire Gauge [Min]	Wire Gauge [Max]
CW Industries CWR-140-40-0003	All	IDC	5.08 mm	40	Tin-Lead	Blue	2.54 µm	100 µin	Through Hole	Ribbon Cable	1.27 mm	0.05 in	2.54 mm	0.1 "	Closed End Strain Relief	Stranded or Solid	27.5 AWG	30 AWG
CW Industries CWR-140-40-0203	All	IDC	5.08 mm	40	Tin	Blue			Through Hole	Ribbon Cable	1.27 mm	0.05 in	2.54 mm	0.1 "	Closed End Strain Relief	Stranded or Solid	27.5 AWG	30 AWG
CW Industries CWR-140-20-0203	All	IDC	5.08 mm	20	Tin	Blue	2.54 µm	100 µin	Through Hole	Ribbon Cable	1.27 mm	0.05 in	2.54 mm	0.1 "	Closed End Strain Relief	Stranded or Solid	27.5 AWG	30 AWG
CW Industries CWR-140-20-0000	All	IDC	5.08 mm	20		Blue			Through Hole	Ribbon Cable	1.27 mm	0.05 in	2.54 mm	0.1 "	Closed End Strain Relief	Stranded or Solid	27.5 AWG	30 AWG
