342-033 Series
Manufacturer: EDAC Inc.
Catalog
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 33 CONTACTS, THROUGH HOLE MOUNT, RIGHT ANGLE
| Part | Operating Temperature [Min] | Operating Temperature [Max] | Color | Termination Rows | Read Out | Number of Positions/Bay/Row [custom] | Card Type | Material - Insulation | Contact Type | Contact Finish | Gender | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Termination | Mounting Type | Pitch [x] | Pitch [x] | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder Wire Wrap | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Copper Alloy |
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder Wire Wrap | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | ||
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder Wire Wrap | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | Copper Alloy |
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Wire Wrap | Through Hole | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Copper Alloy |
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder Wire Wrap | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Copper Alloy | |||
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder Eyelet(s) | Through Hole | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 2.95 mm | Floating Bobbin Flush Mount | 0.116 in | Copper Alloy |
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder Wire Wrap | Through Hole Right Angle | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Side Opening Unthreaded | 0.128 " | Copper Alloy |
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Wire Wrap | Through Hole | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy | ||
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder | Through Hole | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 3.25 mm | Flush Mount Top Opening Unthreaded | 0.128 " | Copper Alloy |
 EDAC Inc. | -40 °C | 105 ░C | Green | 1 | Single | 33 | Non Specified - Single Edge | Polyester Thermoplastic | Cantilever | Gold | Female | 33 | 10 Áin | 0.25 Ám | 1 | Solder | Through Hole | 2.54 mm | 0.1 in | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Flush Mount M3 Threaded Insert Top Opening | Copper Alloy |
