178841 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 3POS 6.2MM
| Part | Contact Finish - Post | Current Rating (Amps) | Number of Positions Loaded | Mounting Type | Number of Rows | Shrouding | Contact Length - Post | Contact Length - Post | Fastening Type | Contact Shape | Contact Type | Insulation Material | Insulation Height | Insulation Height | Features | Insulation Color | Operating Temperature [Min] | Operating Temperature [Max] | Style | Contact Material | Pitch - Mating [x] | Pitch - Mating [x] | Connector Type | Applications | Termination | Material Flammability Rating | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | Tin | Varies by Wire Gauge | All | Through Hole | 1 | Shrouded - 4 Wall | 0.146 in | 3.7 mm | Locking Ramp | Rectangular | Tab | Polyamide (PA66) Nylon 6/6 | 14.3 mm | 0.563 in | Board Guide | Natural | -30 ░C | 105 ░C | Board to Cable/Wire | Copper Alloy | 6.2 mm | 0.244 in | Header | General Purpose | Kinked Pin Solder | UL94 V-0 | |
 TE Connectivity Raychem Cable Protection | Tin | Varies by Wire Gauge | All | Through Hole | 1 | Shrouded - 4 Wall | 0.146 in | 3.7 mm | Locking Ramp | Rectangular | Tab | Polyamide (PA66) Nylon 6/6 | 14.3 mm | 0.563 in | Board Guide | Natural | -30 ░C | 105 ░C | Board to Cable/Wire | Copper Alloy | 6.2 mm | 0.244 in | Header | General Purpose | Kinked Pin Solder | UL94 V-0 | 6 |
