807-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 62POS 0.156
| Part | Number of Positions | Pitch | Pitch | Read Out | Gender | Card Type | Color | Mounting Type | Contact Type | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Contact Finish | Contact Material | Number of Positions/Bay/Row [custom] | Operating Temperature [Max] | Operating Temperature [Min] | Material - Insulation | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 62 | 3.96 mm | 0.156 in | Dual | Female | Non Specified - Dual Edge | Green | Through Hole | Semi Bellows | 2 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Wire Wrap | Tin | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | 62 | 3.96 mm | 0.156 in | Dual | Female | Non Specified - Dual Edge | Green | Right Angle Through Hole | Semi Bellows | 2 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 3.96 mm | 0.156 in | Single | Female | Non Specified - Single Edge | Green | Through Hole | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | 31 | ||
 EDAC Inc. | 62 | 3.96 mm | 0.156 in | Dual | Female | Non Specified - Dual Edge | Green | Through Hole | Semi Bellows | 2 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Wire Wrap | Tin | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||||
 EDAC Inc. | 3.96 mm | 0.156 in | Single | Female | Non Specified - Single Edge | Green | Right Angle Through Hole | Semi Bellows | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | 31 | ||||
 EDAC Inc. | 3.96 mm | 0.156 in | Single | Female | Non Specified - Single Edge | Green | Through Hole | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | 31 | ||
 EDAC Inc. | 3.96 mm | 0.156 in | Single | Female | Non Specified - Single Edge | Green | Through Hole | Semi Bellows | Flush Mount M3 Threaded Insert Top Opening | Wire Wrap | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | 31 | ||||
 EDAC Inc. | 62 | 3.96 mm | 0.156 in | Dual | Female | Non Specified - Dual Edge | Green | Through Hole | Semi Bellows | 2 | Flush Mount M3 Threaded Insert Top Opening | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | 3.96 mm | 0.156 in | Single | Female | Non Specified - Single Edge | Green | Right Angle Through Hole | Semi Bellows | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | 31 | ||
 EDAC Inc. | 3.96 mm | 0.156 in | Single | Female | Non Specified - Single Edge | Green | Through Hole | Semi Bellows | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Gold | Copper Alloy | 31 | 125 °C | -40 C | Diallyl Phthalate (DAP) | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | 31 |
