TPS7A4525 Series

Catalog

IC REG LINEAR 2.5V 1.5A DDPAK

Part	Control Features	Output Configuration	Output Type	Protection Features	Voltage - Output (Min/Fixed)	PSRR	Supplier Device Package	Current - Quiescent (Iq)	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Voltage - Input (Max) [Max]	Number of Regulators	Current - Output	Mounting Type	Voltage Dropout (Max) [Max]
Texas Instruments TPS7A4525KTTR	Enable	Positive	1.81 mOhm	Over Current Over Temperature Reverse Polarity	2.5 V	68 dB	TO-263 (DDPAK-5)	1.5 mA	125 °C	-40 °C	D2PAK (5 Leads + Tab) TO-263-6 TO-263BA	20 V	1	1.5 A	Surface Mount	0.45 V
Texas Instruments TPS7A4525DCQR	Enable	Positive	1.81 mOhm	Over Current Over Temperature Reverse Polarity	2.5 V	68 dB	SOT-223-6	1.5 mA	125 °C	-40 °C	SOT-223-6	20 V	1	1.5 A	Surface Mount	0.45 V
Texas Instruments TPS7A4525DCQT	Enable	Positive	1.81 mOhm	Over Current Over Temperature Reverse Polarity	2.5 V	68 dB	SOT-223-6	1.5 mA	125 °C	-40 °C	SOT-223-6	20 V	1	1.5 A	Surface Mount	0.45 V
