9EC2048 Series

Catalog

FAN AXIAL 200X70MM 48VDC WIRE

Part	Lifetime @ Temp.	Material - Frame	Voltage Range [Max]	Voltage Range [Min]	Air Flow	Air Flow	Current Rating (Amps)	Material - Blade	Termination	Fan Type	Noise	Size / Dimension	Size / Dimension [diameter]	Features	Approval Agency	Bearing Type	Static Pressure	Static Pressure	RPM	Operating Temperature [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Operating Temperature [Min]	Voltage - Rated	Power (Watts)	Width [x]
Sanyo Denki America Inc. 9EC2048J001	40000 Hrs	Aluminum	55.2 VDC	40.8 VDC	646 CFM	18.09 mł/min	4.4 A	Plastic	3 Wire Leads	Tubeaxial	75 dB(A)	Round	200 mm	Locked Rotor Protection Speed Sensor (Tach)	CSA TUV UL	Ball	1000.3 Pa	4.016 in H2O	6100 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	221.2 W	70 mm
Sanyo Denki America Inc. 9EC2048H002	40000 Hrs	Aluminum	52.8 VDC	40.8 VDC	388 CFM	10.86 m³/min	1.2 A	Plastic	2 Wire Leads	Tubeaxial	60 dB(A)	Round	200 mm		CSA TUV UL	Ball	360.2 Pa	1.446 in H2O	3600 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	57.6 W	70 mm
Sanyo Denki America Inc. 9EC2048P0J01	40000 Hrs	Aluminum	55.2 VDC	40.8 VDC	646 CFM	18.09 mł/min	4.4 A	Plastic	4 Wire Leads	Tubeaxial	81 dB(A)	Round	200 mm	Locked Rotor Protection PWM Control Speed Sensor (Tach)	CSA TUV UL	Ball	1000.3 Pa	4.016 in H2O	6100 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	221.2 W	70 mm
Sanyo Denki America Inc. 9EC2048H001	40000 Hrs	Aluminum	52.8 VDC	40.8 VDC	388 CFM	10.86 m³/min	1.2 A	Plastic	3 Wire Leads	Tubeaxial	60 dB(A)	Round	200 mm	Locked Rotor Protection Speed Sensor (Tach)	CSA TUV UL	Ball	360.2 Pa	1.446 in H2O	3600 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	57.6 W	70 mm
Sanyo Denki America Inc. 9EC2048P0A01	40000 Hrs	Aluminum	51 VDC	43 VDC	519 CFM	14.53 m³/min	2.2 A	Plastic	4 Wire Leads	Tubeaxial	68 dB	Round	200 mm	Locked Rotor Protection PWM Control Speed Sensor (Tach)	CSA TUV UL	Ball	640.1 Pa	2.57 in H2O	4800 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	105.6 W	70 mm
Sanyo Denki America Inc. 9EC2048A002	40000 Hrs	Aluminum	51 VDC	43 VDC	519 CFM	14.53 m³/min	2.2 A	Plastic	2 Wire Leads	Tubeaxial	68 dB	Round	200 mm		CSA TUV UL	Ball	640.1 Pa	2.57 in H2O	4800 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	105.6 W	70 mm
Sanyo Denki America Inc. 9EC2048A0D01	40000 Hrs	Aluminum	51 VDC	43 VDC	519 CFM	14.53 m³/min	2.2 A	Plastic	3 Wire Leads	Tubeaxial	68 dB	Round	200 mm	Locked Rotor Sensor	CSA TUV UL	Ball	640.1 Pa	2.57 in H2O	4800 RPM	60 °C	60 °C	-4 °F	-20 ░C	48 VDC	105.6 W	70 mm
