CQ35-25 Series
Manufacturer: SICK, Inc.
Beta
⌘K
CAP PROX SENSOR, 25MM, COMP NPN, 36V ROHS COMPLIANT: YES
| Part | Voltage - Supply [Max] | Voltage - Supply [Min] | Sensing Distance [Min] | Sensing Distance [Max] | Output Type | Indicator | Ingress Protection | Termination Style | Package / Case | Sensor Type | Material - Body | Response Frequency | Shielding | Operating Temperature [Min] | Operating Temperature [Max] | Output Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SICK, Inc. | 36 V | 10 VDC | 0.157 " 4 mm | 0.984 " 25 mm | 4-Wire NPN-NC/NO | LED | IP67 | Connector | Module | Capacitive | Plastic | 50 Hz | Shielded | -25 °C | 75 °C | |
 SICK, Inc. | 36 V | 10 VDC | 0.157 " 4 mm | 0.984 " 25 mm | 4-Wire PNP-NC | LED | IP67 | Cable Leads | Flange Mount | Capacitive | Plastic | 50 Hz | Unshielded | -25 °C | 75 ░C | |
 SICK, Inc. | 36 V | 10 VDC | 0.157 " 4 mm | 0.984 " 25 mm | 4-Wire PNP-NC | LED | IP67 | Connector | Flange Mount | Capacitive | Plastic | 50 Hz | Unshielded | -25 °C | 75 ░C | |
SICK, Inc. | 36 V | 10 VDC | 0.157 " 4 mm | 0.984 " 25 mm | NPN-NO | LED | IP67 | Cable Leads | Flange Mount | Capacitive | Plastic | 50 Hz | Unshielded | -25 °C | 75 ░C | 4 Pole |
