680-044 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB HD PLUG 44POS PNL MNT
| Part | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Contact Form | Dielectric Material | Ingress Protection | Number of Rows [custom] | Connector Style | Shell Material, Finish | Connector Type | Contact Finish Thickness | Current Rating (Amps) | Termination | Shell Size, Connector Layout | Contact Finish | Contact Type | Mounting Type | Material Flammability Rating | Flange Feature | Features | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 100 °C | -50 °C | Brass | Stamped | Polybutylene Terephthalate (PBT) | IP66 - Dust Tight Water Resistant | 3 | D-Sub High Density | Nickel Plated Steel | Plug Male Pins | Flash | 5 A | Solder | 3 | Gold | Signal | Panel Mount Through Hole | UL94 V-0 | Board Side (4-40) | Board Lock Grounding Indents | 44 |
 NorComp Inc. | 100 °C | -50 °C | Brass | Stamped | Polybutylene Terephthalate (PBT) Glass Filled | IP66 - Dust Tight Water Resistant | 3 | D-Sub High Density | Nickel Plated Steel | Plug Male Pins | Flash | 5 A | Solder | 3 | Gold | Signal | Panel Mount Through Hole | UL94 V-0 | Grounding Indents | 44 | |
NorComp Inc. | 100 °C | -50 °C | Brass | Stamped | Polybutylene Terephthalate (PBT) | IP66 - Dust Tight Water Resistant | 3 | D-Sub High Density | Nickel Plated Steel | Plug Male Pins | Flash | 5 A | Solder | 3 | Gold | Signal | Panel Mount Through Hole | UL94 V-0 | 4-40 | Grounding Indents | 44 |
NorComp Inc. | 100 °C | -50 °C | Brass | Stamped | Polybutylene Terephthalate (PBT) | IP66 - Dust Tight Water Resistant | 3 | D-Sub High Density | Nickel Plated Steel | Plug Male Pins | Flash | 5 A | 3 | Gold | Signal | Panel Mount | UL94 V-0 | Cable Side (4-40) | Grounding Indents | 44 | |
NorComp Inc. | 100 °C | -50 °C | Brass | Stamped | Polybutylene Terephthalate (PBT) | IP66 - Dust Tight Water Resistant | 3 | D-Sub High Density | Nickel Plated Steel | Plug Male Pins | Flash | 5 A | 3 | Gold | Signal | Panel Mount | UL94 V-0 | Housing/Shell (Unthreaded) | Grounding Indents | 44 |
