C284AC Series

Manufacturer: KEMET

Catalog

CAP FILM 5UF 5% 470VAC RADIAL

Part	Termination	Capacitance	Size / Dimension	Size / Dimension [diameter]	Voltage Rating - AC	Dielectric Material	Mounting Type	Operating Temperature [Max]	Operating Temperature [Min]	Package / Case	Tolerance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Applications	Size / Dimension [diameter]
KEMET C284ACA4500AL0J	Wire Leads	5 µF	30 mm	1.181 "	470 V	Polypropylene (PP)	Chassis Mount	85 °C	-25 °C	Can Radial	5 %	57 mm	2.244 "	Motor Run
KEMET C284ACR4300AL0J	Wire Leads	3 µF		0.984 "	470 V	Polypropylene (PP)	Chassis Mount	85 °C	-25 °C	Can Radial	5 %	57 mm	2.244 "	Motor Run	25 mm
KEMET C284ACA4400AL0J	Wire Leads	4 µF	30 mm	1.181 "	470 V	Polypropylene (PP)	Chassis Mount	85 °C	-25 °C	Can Radial	5 %	57 mm	2.244 "	Motor Run
KEMET C284ACA4300AL0J	Wire Leads	3 µF		0.984 "	470 V	Polypropylene (PP)	Chassis Mount	85 °C	-25 °C	Can Radial	5 %	57 mm	2.244 "	Motor Run	25 mm
KEMET C284ACA4200AL0J	Wire Leads	2 µF		0.984 "	470 V	Polypropylene (PP)	Chassis Mount	85 °C	-25 °C	Can Radial	5 %	57 mm	2.244 "	Motor Run	25 mm
KEMET C284ACA4250AL0J	Wire Leads	2.5 µF		0.984 "	470 V	Polypropylene (PP)	Chassis Mount	85 °C	-25 °C	Can Radial	5 %	57 mm	2.244 "	Motor Run	25 mm
