LUMOTAST 22 E-Stop Series
Manufacturer: RAFI USA
Beta
⌘K
EMERGENCY STOP SWITCHES / E-STOP SWITCHES E-STOP 2NC ILLUMINATED
| Part | Ingress Protection | Voltage Rating - DC | Mounting Type | Features | Reset Operation | Termination Style | Switch Function | Panel Cutout Dimensions [diameter] | Voltage Rating - AC | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Circuit |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RAFI USA | IP65 - Dust Tight Water Resistant | 240 VDC | Panel Mount Front | Status Indicator | Twist | Solder Quick Connect - 0.110" (2.8mm) | On-Off | 22.3 mm | 250 V | -25 °C | 70 °C | 2.5 A | DPST-NC |
 RAFI USA | IP65 - Dust Tight Water Resistant | 240 VDC | Panel Mount Front | Status Indicator | Twist | Solder Quick Connect - 0.110" (2.8mm) | Off-On On-Off | 22.3 mm | 250 V | -25 °C | 70 °C | 2.5 A | 3PST-2NC/1NO |
RAFI USA | IP65 - Dust Tight Water Resistant | 240 VDC | Panel Mount Front | Status Indicator | Twist | Solder Quick Connect - 0.110" (2.8mm) | On-Off | 22.3 mm | 250 V | -25 °C | 70 °C | 2.5 A | DPST-NC |
