29878 Series
Manufacturer: Phoenix Contact
Beta
⌘K
POWER RELAY, SPDT, 3A, 250A ROHS COMPLIANT: YES
| Part | Coil Resistance | Contact Rating (Current) | Coil Type | Features | Coil Current | Mounting Type | Operate Time | Relay Type | Switching Voltage | Approval Agency | Coil Voltage | Contact Form | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Release Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 1.3 kOhms | 16 A | Non Latching | Diode Lighted Indicator Mechanical Indicator | 18 mA | Through Hole | 9 ms | General Purpose | 250 VAC 250 VDC | cULus EAC UR | 24 VDC | SPDT (1 Form C) | PC Pin | 70 °C | -40 C | Silver Nickel (AgNi) | 6 ms |
 Phoenix Contact | 750 Ohms | 16 A | Non Latching | Mechanical Indicator Test Button | 32 mA | Through Hole | 12 ms | General Purpose | 250 VAC 250 VDC | cULus EAC UR | 24 VAC | SPDT (1 Form C) | PC Pin | 70 °C | -40 C | Silver Nickel (AgNi) | 8 ms |
