GS-115 Series
Manufacturer: CW Industries
Beta
⌘K
SWITCH SLIDE SPDT 500MA 125V
| Part | Switch Travel | Actuator Material | Mechanical Life | Contact Finish | Mounting Type | Current Rating (Amps) | Switch Function | Termination Style | Circuit | Actuator Type | Actuator Length [x] | Voltage Rating - AC | Contact Material | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating - DC | Contact Timing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Through Hole | 500 mA | On-On | PC Pin | SPDT | Standard | 3.56 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Through Hole | 500 mA | On-On | Press-Fit | SPDT | Standard | 3.18 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Panel Mount | 500 mA | On-On | PC Pin | SPDT | Standard | 3.56 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Through Hole | 500 mA | On-On | PC Pin | SPDT | Standard | 4.29 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Panel Mount | 500 mA | On-On | Press-Fit | SPDT | Standard | 3.18 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
 CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Panel Mount | 500 mA | On-On | Solder Lug | SPDT | Standard | 3.18 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Panel Mount | 500 mA | On-On | PC Pin | SPDT | Standard | 3.56 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
 CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Through Hole | 500 mA | On-On | PC Pin | SPDT | Standard | 3.18 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Panel Mount | 500 mA | On-On | Press-Fit | SPDT | Standard | 4.75 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
CW Industries | 2.67 mm | Nylon 6/6 Polyamide (PA66) | 10000 Steps | Silver | Panel Mount | 500 mA | On-On | PC Pin | SPDT | Standard | 4.29 mm | 125 V | Copper Alloy | -10 °C | 104 °C | 125 VDC | Not Specified |
