202706 Series
Manufacturer: Molex
Catalog
1.50MM PITCH, PICO-SPOX PCB HEADER, SINGLE ROW, RIGHT-ANGLE, SURFACE MOUNT, GOLD (AU) FLASH PLATING, FRICTION LOCK, 2 CIRCUITS, TAPE AND REEL, WITHOUT CAP, BEIGE
| Part | Applications | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Termination | Style | Number of Positions | Connector Type | Number of Rows | Insulation Color | Mounting Type | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Insulation Material | Shrouding | Voltage Rating | Contact Finish - Post | Contact Shape | Contact Material | Material Flammability Rating | Insulation Height [z] | Insulation Height [z] | Contact Type | Current Rating (Amps) | Number of Positions Loaded | Contact Finish - Mating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | General Purpose | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 2 | Header | 1 | Beige | Right Angle Surface Mount | Friction Lock | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold |
 Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 6 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
 Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 7 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 8 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
 Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 10 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 9 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 13 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
 Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 11 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
 Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 4 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold | |
Molex | 0.1 Ám | 3.94 Áin | Solder | Board to Cable/Wire | 15 | Header | 1 | Beige | Right Angle Surface Mount | Push-Pull | -55 C | 105 ░C | 3.94 µin | 0.1 µm | Nylon Polyamide (PA) | Shrouded - 4 Wall | 250 VAC | Gold | Square | Brass | UL94 V-0 | 4.45 mm | 0.175 in | Male Pin | Varies by Wire Gauge | All | Gold |
