FGC.2B Series

Manufacturer: LEMO

Catalog

CONN PLUG MALE 19P GOLD SLDR CUP

Part	Fastening Type	Contact Finish - Mating	Shell Size - Insert	Operating Temperature [Min]	Operating Temperature [Max]	Shielding	Orientation	Color	Number of Positions	Material Flammability Rating	Primary Material	Contact Material	Current Rating (Amps)	Backshell Material, Plating	Connector Type	Shell Finish	Ingress Protection	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Min]	Cable Opening [Max]	Mounting Type	Features	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Shell Material	Insert Material	Shell Size - Insert [custom]	Termination	Cable Opening [Min]	Cable Opening [Max]
LEMO FGC.2B.319.CLAD99Z	Push-Pull	Gold	319	-55 C	250 °C	Shielded	C	Silver	19	UL94 V-0	Metal	Brass	5 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.39 in	0.362 in	9.2 mm	9.9 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)
LEMO FGC.2B.316.CLAD52Z	Push-Pull	Gold		-55 C	250 °C	Shielded	C	Silver	16	UL94 V-0	Metal	Brass	6 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.205 in	0.165 "	4.2 mm	5.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)	316
LEMO FGC.2B.306.CYCD52Z	Push-Pull	Gold	306	-55 C	250 °C	Shielded	C	Silver	6	UL94 V-0	Metal	Brass	12 Amps	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.205 in	0.165 "	4.2 mm	5.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)		Crimp
LEMO FGC.2B.310.CLAD52Z	Push-Pull	Gold	310	-55 C	250 °C	Shielded	C	Silver	10	UL94 V-0	Metal	Brass	8 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.205 in	0.165 "	4.2 mm	5.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)
LEMO FGC.2B.319.CLAD92Z	Push-Pull	Gold	319	-55 C	250 °C	Shielded	C	Silver	19	UL94 V-0	Metal	Brass	5 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.362 in	0.323 in	8.2 mm	9.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)
LEMO FGC.2B.310.CLAD99	Push-Pull	Gold	310	-55 C	250 °C	Shielded	C	Silver	10	UL94 V-0	Metal	Brass	8 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.39 in	0.362 in	9.2 mm	9.9 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)
LEMO FGC.2B.310.CYGD52Z	Push-Pull	Gold	310	-55 C	250 °C	Shielded	C	Silver	10	UL94 V-0	Metal	Brass	8 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.205 in	0.165 "	4.2 mm	5.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)		Crimp
LEMO FGC.2B.319.CLAD72	Push-Pull	Gold	319	-55 C	250 °C	Shielded	C	Silver	19	UL94 V-0	Metal	Brass	5 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected			6.2 mm	7.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)			0.244 in	0.283 in
LEMO FGC.2B.319.CLAD92Y	Push-Pull	Gold	319	-55 C	250 °C	Shielded	C	Silver	19	UL94 V-0	Metal	Brass	5 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected	0.362 in	0.323 in	8.2 mm	9.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)
LEMO FGC.2B.319.CLAD72Z	Push-Pull	Gold	319	-55 C	250 °C	Shielded	C	Silver	19	UL94 V-0	Metal	Brass	5 A	Brass Chrome	Plug Male Pins	Chrome	IP50 - Dust Protected			6.2 mm	7.2 mm	Free Hanging (In-Line)	Backshell	39.4 µin	1 µm	Brass	Polyetheretherketone (PEEK)			0.244 in	0.283 in
