173-E50 Series
Manufacturer: NorComp Inc.
Beta
⌘K
173-E50-113R241 ROHS COMPLIANT: YES
| Part | Dielectric Material | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Rating | Color | Contact Material | Backset Spacing | Backset Spacing | Features | Flange Feature | Contact Finish | Connector Type | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Termination | Shell Material, Finish | Contact Finish Thickness | Connector Style | Material Flammability Rating | Number of Rows [custom] | Contact Type | Number of Positions | Mounting Type | Flange Feature | Shell Material, Finish [custom] | Shell Material, Finish [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | 500 V | White | Brass | 7.2 mm | 0.283 in | Grounding Indents Mounting Brackets | Mating Side Standard Screws (4-40) | Gold | Plug Male Pins | 5 A | 5 | D DD | Solder | Nickel Plated Steel | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole | |||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | Brass | 7.2 mm | 0.283 in | Grounding Indents | Housing/Shell (Unthreaded) | Gold | Plug Male Pins | 5 A | 5 | D DD | Solder | Nickel Plated Steel | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | Brass | 7.2 mm | 0.283 in | Grounding Indents Mounting Brackets | 4-40 Mating Side Female Screwlock | Gold | Plug Male Pins | 5 A | 5 | D DD | Solder | Nickel Plated Steel | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 125 °C | -55 C | White | Copper | 7.2 mm | 0.283 in | Board Lock Mounting Brackets | Housing/Shell | Gold | Receptacle Female Sockets | 5 A | 5 | D DD | Solder | Nickel Plated Steel | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Right Angle Through Hole | 4-40 | |||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | 7.2 mm | 0.283 in | Housing/Shell (Unthreaded) | Gold | Receptacle Female Sockets | 5 A | 5 | D DD | Solder | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole | Steel | Yellow Chromate Plated | |||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | Brass | 7.2 mm | 0.283 in | Mounting Brackets | 4-40 Mating Side Female Screwlock | Gold | Plug Male Pins | 5 A | 5 | D DD | Solder | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole | Steel | Yellow Chromate Plated | |||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 125 °C | -55 C | White | Copper | 7.2 mm | 0.283 in | Mounting Brackets | 4-40 Mating Side Female Screwlock | Gold | Receptacle Female Sockets | 5 A | 5 | D DD | Solder | Nickel Plated Steel | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Right Angle Through Hole | ||||
 NorComp Inc. | Polyamide (PA6T) Nylon 6T | 100 °C | -50 °C | White | 7.2 mm | 0.283 in | Mounting Brackets | 4-40 Mating Side Female Screwlock | Gold | Receptacle Female Sockets | 5 A | 5 | D DD | Solder | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole | Steel | Yellow Chromate Plated | ||||
NorComp Inc. | Polybutylene Terephthalate (PBT) | 100 °C | -50 °C | White | 7.2 mm | 0.283 in | Housing/Shell (Unthreaded) | Gold | Receptacle Female Sockets | 5 A | 5 | D DD | Solder | Flash | D-Sub | UL94 V-0 | 3 | Signal | 50 | Panel Mount Right Angle Through Hole |
