BR24G32FVT-5 Series
32KBit, I²C BUS, High Endurance, Low Power Serial EEPROM
Manufacturer: Rohm Semiconductor
Catalog
32KBit, I²C BUS, High Endurance, Low Power Serial EEPROM
| Part | Voltage - Supply [Max] | Voltage - Supply [Min] | Mounting Type | Memory Organization [custom] | Memory Organization [custom] | Memory Format | Supplier Device Package | Write Cycle Time - Word, Page | Operating Temperature [Max] | Operating Temperature [Min] | Memory Type | Memory Size | Technology | Memory Interface | Package / Case | Package / Case [y] | Package / Case [x] | Package / Case [custom] | Package / Case | Package / Case [custom] | Clock Frequency | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 5.5 V | 1.7 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-SOP-J | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-SOIC | 3.9 mm | 0.154 in | |||||
 Rohm Semiconductor | 5.5 V | 1.7 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-MSOP | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-MSOP 8-VSSOP | |||||||
 Rohm Semiconductor | 5.5 V | 1.7 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-TSSOP-BJ | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-MSOP 8-TSSOP | 0.118 in | 3 mm | |||||
 Rohm Semiconductor | 5.5 V | 1.7 V | Surface Mount | 4 K | 8 bits | EEPROM | VSON008X2030 | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-UFDFN Exposed Pad | |||||||
Rohm Semiconductor | 5.5 V | 1.6 V | Surface Mount | 4 K | 8 bits | EEPROM | VSON008X2030 | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-UFDFN Exposed Pad | |||||||
 Rohm Semiconductor | 5.5 V | 1.6 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-TSSOP-B | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-TSSOP | 0.173 " | 4.4 mm | 400 kHz | ||||
 Rohm Semiconductor | 5.5 V | 1.6 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-TSSOP-B | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-TSSOP | 0.173 " | 4.4 mm | |||||
 Rohm Semiconductor | 5.5 V | 1.6 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-MSOP | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-MSOP 8-VSSOP | |||||||
 Rohm Semiconductor | 5.5 V | 1.7 V | Through Hole | 4 K | 8 bits | EEPROM | 8-DIP-T | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-DIP | 0.3 in | 7.62 mm | |||||
 Rohm Semiconductor | 5.5 V | 1.6 V | Surface Mount | 4 K | 8 bits | EEPROM | 8-SSOP-B | 5 ms | 85 °C | -40 °C | Non-Volatile | 32 Kbit | EEPROM | I2C | 8-LSSOP (0.173" 4.40mm Width) | 400 kHz |
Key Features
• All Controls Available by 2 Ports of Serial Clock (SCL) and Serial Data (SDA), 1.6 V to 5.5 V Wide Limit of Operating Voltage, Possible 1 MHz Operation, Page Write Mode 32 Bytes, Bit Format 4K x 8 bits, Low Current Consumption, Prevention of Miswriting· WP (Write Protect) Function Added· Prevention of Miswriting at Low Voltage, Noise Filter Built-in SCL / SDA Pin, Initial Delivery State FFh
Description
AI
BR24G32FVT-5 is a 32kbit serial EEPROM of I²C BUS Interface.
