2842236 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

20P, AMPMODU 2MM, DOUBLE ROW SHR

Part	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Style	Applications	Insulation Material	Number of Positions Loaded	Insulation Height [z]	Insulation Height [z]	Shrouding	Pitch - Mating [x]	Pitch - Mating [x]	Current Rating (Amps)	Contact Finish - Post	Contact Type	Mounting Type	Contact Length - Mating	Contact Length - Mating	Connector Type	Contact Material	Number of Rows	Material Flammability Rating	Contact Length - Post	Contact Length - Post	Insulation Color	Voltage Rating	Contact Finish - Mating	Termination	Operating Temperature [Max]	Operating Temperature [Min]	Row Spacing - Mating	Row Spacing - Mating	Number of Positions	Fastening Type	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Shape	Number of Positions
TE Connectivity Raychem Cable Protection 2-2842236-0	3.94 µin	0.1 µm	Board to Board Cable	General Purpose Industrial	Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.141 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm	20	Detent Lock	2 çm	78.7 çin	Square
TE Connectivity Raychem Cable Protection 3-2842236-4	3.94 µin	0.1 µm	Board to Board Cable		Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.142 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm	34	Detent Lock	2 çm	78.7 çin	Square
TE Connectivity Raychem Cable Protection 4-2842236-0	3.94 µin	0.1 µm	Board to Board Cable		Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.142 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm	40	Detent Lock	2 çm	78.7 çin	Square
TE Connectivity Raychem Cable Protection 2-2842236-6	3.94 µin	0.1 µm	Board to Board Cable		Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.142 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm	26	Detent Lock	2 çm	78.7 çin	Square
TE Connectivity Raychem Cable Protection 2-2842236-4	3.94 µin	0.1 µm	Board to Board Cable		Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.142 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm	24	Detent Lock	2 çm	78.7 çin	Square
TE Connectivity Raychem Cable Protection 1-2842236-6	3.94 µin	0.1 µm	Board to Board Cable	General Purpose Industrial	Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.141 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm		Detent Lock	2 çm	78.7 çin	Square	16
TE Connectivity Raychem Cable Protection 1-2842236-4	3.94 µin	0.1 µm	Board to Board Cable	General Purpose Industrial	Thermoplastic	All	6.4 mm	0.252 in	Shrouded - 4 Wall	0.079 in	2 mm	2 A	Tin	Male Pin	Through Hole	0.141 in	3.6 mm	Header	Copper Alloy	2	UL94 V-0	2.5 mm	0.098 in	Black	125 VAC	Gold	Solder	125 °C	-40 °C	0.079 in	2 mm	14	Detent Lock	2 çm	78.7 çin	Square
