TS14 Series

Catalog

TERM BLOCK PLUG 3POS 7.62MM

...

Part	Insulation Height	Insulation Height	Positions Per Level	Plug Wire Entry	Mounting Type	Contact Material	Pitch [x]	Pitch [x]	Number of Levels	Screw Size	Type	Wire Strip Length [Max]	Wire Strip Length [Min]	Torque - Screw	Torque - Screw	Color	Material Flammability Rating	Housing Material	Voltage - UL	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Operating Temperature [Min]	Operating Temperature [Max]	Contact Mating Finish	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Termination Style	Wire Gauge or Range - mm˛ [Min]	Wire Gauge or Range - mm˛ [Max]	Current - UL	Number of Positions	Features	Wire Gauge or Range - mm²
Amphenol Anytek TS03010B0000G	1.024 "	26.01 mm	3	270 °	Free Hanging (In-Line)	Phosphor Bronze	0.3 in	7.62 mm	1	M3	Plug Female Sockets	7 mm	6 mm	0.4 Nm	3.5 Lb-In	Black	UL94 V-0	Thermoplastic	300 V	24 AWG	12 AWG	-40 °C	115 °C	Tin	0.2 mm²	2.5 mm²	Screw - Leaf Spring Wire Guard
Amphenol Anytek TS10315C0000G	0.751 in	19.08 mm	10	90 °	Free Hanging (In-Line)	Copper Alloy	0.15 in	3.81 mm	1	M2	Plug Female Sockets	7 mm	6 mm	0.2 Nm	1.7 Lb-In	Green	UL94 V-0	Thermoplastic Resin	300 V	28 AWG	16 AWG	-40 °C	115 °C	Tin			Screw - Rising Cage Clamp	0.5 mm˛	1.5 mm˛	8 A	10	Mating Flange
Amphenol Anytek TS03518C0000G	1.024 "	26.01 mm	3	90 °	Free Hanging (In-Line)	Phosphor Bronze	0.2 in	5.08 mm	1	M3	Plug Female Sockets	7 mm	6 mm	0.4 Nm	3.5 Lb-In	Gray	UL94 V-0	Thermoplastic	300 V	24 AWG	12 AWG	-40 °C	115 °C	Tin	0.34 mm²	2.5 mm²	Screw - Leaf Spring Wire Guard					Mating Flange Retention Latches (Wire Side)
Amphenol Anytek TS15115A0000G	0.76 in	19.3 mm	15	90 °	Free Hanging (In-Line)	Copper Alloy	0.138 in	3.5 mm	1	M2	Plug Female Sockets	7 mm	6 mm	0.2 Nm	1.7 Lb-In	Green	UL94 V-0	Thermoplastic Resin	300 V	28 AWG	16 AWG	-40 °C	115 °C	Tin	0.5 mm²	1.5 mm²	Screw - Rising Cage Clamp			8 A	15
Amphenol Anytek TS08010B0000G	1.024 "	26.01 mm	8	270 °	Free Hanging (In-Line)	Phosphor Bronze	0.3 in	7.62 mm	1	M3	Plug Female Sockets	7 mm	6 mm	0.4 Nm	3.5 Lb-In	Black	UL94 V-0	Thermoplastic	300 V	24 AWG	12 AWG	-40 °C	115 °C	Tin			Screw - Leaf Spring Wire Guard	0.2 mm˛	2.5 mm˛		8
Amphenol Anytek TS14518B0000G	1.024 "	26.01 mm	14	270 °	Free Hanging (In-Line)	Phosphor Bronze	0.2 in	5.08 mm	1	M3	Plug Female Sockets	7 mm	6 mm	0.4 Nm	3.5 Lb-In	Gray	UL94 V-0	Thermoplastic	300 V	24 AWG	12 AWG	-40 °C	115 °C	Tin	0.34 mm²	2.5 mm²	Screw - Leaf Spring Wire Guard				14
Amphenol Anytek TS17718D0000G	1.024 "	26.01 mm	17	270 °	Free Hanging (In-Line)	Phosphor Bronze	0.197 in	5 mm	1	M3	Plug Female Sockets	7 mm	6 mm	0.4 Nm	3.5 Lb-In	Gray	UL94 V-0	Thermoplastic	300 V	24 AWG	12 AWG	-40 °C	115 °C	Tin	0.34 mm²	2.5 mm²	Screw - Leaf Spring Wire Guard					Mating Flange Retention Latches (Non-Wire Side)
Amphenol Anytek TS24315B0000G	0.752 "	19.1 mm		270 °	Free Hanging (In-Line)	Phosphor Bronze	0.15 in	3.81 mm	1	M2	Plug Female Sockets	7 mm	6 mm	0.2 Nm	1.7 Lb-In	Green	UL94 V-0	Thermoplastic	300 V	28 AWG	16 AWG	-40 °C	115 °C	Tin			Screw - Leaf Spring Wire Guard			8 A	24		1.5 mm²
Amphenol Anytek TS21515A0000G	1.024 "	26.01 mm	21	90 °	Free Hanging (In-Line)	Copper Alloy	0.2 in	5.08 mm	1	M3	Plug Female Sockets	7 mm	6 mm	0.4 Nm	3.5 Lb-In	Green	UL94 V-0	Thermoplastic Resin	300 V	24 AWG	12 AWG	-40 °C	115 °C	Tin			Screw - Rising Cage Clamp	1 mm˛	2.5 mm˛	12 A	21	Retention Latches (Wire Side)
Amphenol Anytek TS02310C0000G	0.752 "	19.1 mm	2	90 °	Free Hanging (In-Line)	Phosphor Bronze	0.15 in	3.81 mm	1	M2	Plug Female Sockets	7 mm	6 mm	0.2 Nm	1.7 Lb-In	Black	UL94 V-0	Thermoplastic	300 V	28 AWG	16 AWG	-40 °C	115 °C	Tin			Screw - Leaf Spring Wire Guard			8 A	2	Mating Flange	1.5 mm²
