146258 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN HEADER VERT 6POS 2.54MM

Part	Contact Length - Post	Contact Length - Post	Number of Positions	Contact Finish - Post	Connector Type	Fastening Type	Insulation Height	Insulation Height	Number of Positions Loaded	Insulation Color	Material Flammability Rating	Termination	Contact Type	Insulation Material	Contact Length - Mating [x]	Contact Length - Mating	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Operating Temperature [Min]	Operating Temperature [Max]	Contact Shape	Overall Contact Length	Overall Contact Length	Shrouding	Pitch - Mating	Pitch - Mating	Mounting Type	Contact Material	Style	Current Rating (Amps)	Number of Rows	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]
TE Connectivity Raychem Cable Protection 9-146258-0-03	0.09 "	2.29 mm	6	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-01	0.09 "	2.29 mm	2	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded			Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-11	0.09 "	2.29 mm	22 positions	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-06	0.09 "	2.29 mm	12	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-28	0.09 "	2.29 mm	56	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-09	0.09 "	2.29 mm	18	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-16	0.09 "	2.29 mm		Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-10	0.09 "	2.29 mm	20	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-17	0.09 "	2.29 mm	34	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
TE Connectivity Raychem Cable Protection 9-146258-0-35	0.09 "	2.29 mm	70	Tin	Breakaway Header	Push-Pull	0.09 in	2.29 mm	All	Black	UL94 V-0	Solder	Male Pin	Liquid Crystal Polymer (LCP)	0.23 in	5.84 mm	2.54 µm	100 µin	-65 ░C	105 ░C	Square	0.41 in	10.41 mm	Unshrouded	0.1 in	2.54 mm	Through Hole	Copper Alloy	Board to Board Cable	3 A	2	2.54 çm	100 çin	2.54 mm	0.1 in
