807-041 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 41POS 0.156
| Part | Material - Insulation | Termination Rows | Gender | Card Thickness [Max] | Card Thickness [Min] | Read Out | Number of Positions | Contact Material | Number of Positions/Bay/Row | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Pitch | Pitch | Color | Card Type | Contact Finish | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Termination | Mounting Type | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Copper Alloy | 41 | 1 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Single Edge | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder Eyelet(s) | Through Hole | Semi Bellows | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Copper Alloy | 41 | 1 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Single Edge | Gold | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder Eyelet(s) | Through Hole | Semi Bellows | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Tin | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Solder | Through Hole | Semi Bellows | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Tin | Wire Wrap | Through Hole | Semi Bellows | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Gold | Solder Eyelet(s) | Through Hole | Semi Bellows | 0.25 Ám | 10 Áin | 2 | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Gold | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Solder | Right Angle Through Hole | Semi Bellows | 0.25 Ám | 10 Áin | 2 | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Single | 41 | Copper Alloy | 41 | 1 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Single Edge | Gold | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Solder Eyelet(s) | Through Hole | Semi Bellows | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Tin | Solder | Right Angle Through Hole | Semi Bellows | 2 | ||||||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Solder | Right Angle Through Hole | Semi Bellows | 0.25 Ám | 10 Áin | 2 | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Dual | 82 | Copper Alloy | 41 | 125 °C | -40 C | 3.96 mm | 0.156 in | Green | Non Specified - Dual Edge | Tin | Flush Mount M3 Threaded Insert Top Opening | Solder Eyelet(s) | Through Hole | Semi Bellows | 2 |
