FAN4603 Series

Catalog

DC DC CONVERTER 1.8V

Part	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Output 1	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Input (Max) [Max]	Features	Voltage - Input (Min) [Min]	Efficiency	Mounting Type	Applications	Package / Case	Type	Current - Output (Max) [Max]	Number of Outputs
ON Semiconductor FAN4603MM13X	85 °C	-40 °C	1.8 V	0.04 in	0.1 in	4 mm	1.1 mm	2.5 mm	0.16 in	5.5 V	OCP OTP SCP UVLO	2.3 V	91 %	Surface Mount	ITE (Commercial)	6-PowerTDFN Module	Non-Isolated PoL Module	600 mA	1
ON Semiconductor FAN4603MM10X	85 °C	-40 °C	1 V	0.04 in	0.1 in	4 mm	1.1 mm	2.5 mm	0.16 in	5.5 V	OCP OTP SCP UVLO	2.3 V	91 %	Surface Mount	ITE (Commercial)	6-PowerTDFN Module	Non-Isolated PoL Module	600 mA	1
ON Semiconductor FAN4603MM18X	85 °C	-40 °C	1.82 V	0.04 in	0.1 in	4 mm	1.1 mm	2.5 mm	0.16 in	5.5 V		2.3 V	91 %	Surface Mount	ITE (Commercial)	6-PowerTDFN Module	Non-Isolated PoL Module	600 mA	1
ON Semiconductor FAN4603MM13X	85 °C	-40 °C	1.8 V	0.04 in	0.1 in	4 mm	1.1 mm	2.5 mm	0.16 in	5.5 V	OCP OTP SCP UVLO	2.3 V	91 %	Surface Mount	ITE (Commercial)	6-PowerTDFN Module	Non-Isolated PoL Module	600 mA	1
