681S9W4 Series
Manufacturer: NorComp Inc.
Beta
⌘K
COMBINATION LAYOUT D SUB CONNECTOR, SEAL-D, IP68, SEAL-D 681S SERIES, DB-9W4, RECEPTACLE
| Part | Contact Material | Dielectric Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Ingress Protection | Shell Material, Finish | Mounting Type | Termination | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [x] | Material Flammability Rating | Number of Rows [custom] | Contact Finish | Connector Style | Current Rating (Amps) [Max] | Current Rating (Amps) [Min] | Current Rating (Amps) | Contact Finish Thickness | Flange Feature | Number of Positions [custom] | Number of Positions [custom] | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | Copper Alloy | Polybutylene Terephthalate (PBT) | Black | -55 C | 125 °C | Signal and Power | IP67 - Dust Tight Waterproof | Nickel Plated Steel | Panel Mount Through Hole | Solder | DB B - 9W4 | 3 | UL94 V-0 | 2 | Gold | Combo D-Sub | 40 A | 20 A | 5 A | Flash | Housing/Shell (Unthreaded) | 4 | 5 | Receptacle Female Sockets |
