PJL9812 Series
Manufacturer: Panjit International Inc.
Beta
⌘K
TRANSISTOR MOSFET ARRAY DUAL N-CH 30V 8-PIN SOP T/R
| Part | Supplier Device Package | Mounting Type | Vgs(th) (Max) @ Id | Operating Temperature [Max] | Operating Temperature [Min] | Package / Case | Package / Case | Package / Case | Power - Max [Max] | Configuration | Drain to Source Voltage (Vdss) | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Technology | Rds On (Max) @ Id, Vgs | Current - Continuous Drain (Id) @ 25°C |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panjit International Inc. | 8-SOP | Surface Mount | 1.3 V | 150 °C | -55 °C | 0.154 in | 8-SOIC | 3.9 mm | 2 W | 2 N-Channel (Dual) | 30 V | 5.1 nC | 421 pF | MOSFET (Metal Oxide) | 35 mOhm | 6 A |
